optical spectrum analyzer

Key FeaturesWavelength Range: 350 nm to 1000 nmWavelength Resolution (at 650 nm): 0.05 nm (standard), 0.01 nm (option)Peak Wavelength Measurement Resolution: 0.001 nmWavelength Measurement Accuracy: ±0.05 nm (standard), ±0.01 nm (option)Coherence Measurement Resolution: 0.001 mmCoherence Measurement Length: Approx. 10 mm (standard), Approx. 40 mm (option)Maximum Input Level: ±10 dBmLevel Sensitivity: -80 dBm to +20 dBmDynamic Range: 60 dBSweep Time: 1 ms to 500 msMeasurement Speed: Fast sweep option of 0.5 s for full-span measurementsDisplay: 8.4-inch color LCDInterfaces: GPIB, RS-232C, EthernetPower Supply: 100-240 V AC, 50/60 HzDimensions: 426 mm (W) × 173 mm (H) × 546 mm (D)Weight: Approximately 18 kgAdditional CharacteristicsUses a built-in He-Ne laser as a wavelength reference source to ensure high wavelength measurement accuracyEffective for evaluating CD/DVD laser diodes as well as blue-violet laser diodesIdeal for evaluating temperature characteristics of system components due to fast measurement speedSuitable for manufacturing and production environments with high throughput capabilitiesSmall and lightweight platform
