Multi-channel optical power meter

Key Features4-channel module – Four independent simultaneous measurement channels per moduleWide wavelength range – 1250 to 1680 nm (specification range: 1250 to 1630 nm)Broad power dynamic range – –80 to +10 dBmHigh power resolution – 0.001 dBExcellent linearity – ±0.03 dB (typical, –55 to +9 dBm range)Low polarization dependence – PDS < 0.025 dB (1525–1585 nm)InGaAs detector – Covers S/C/L communication bandsHigh-speed measurement – Up to 100 kHz sampling rateLarge data logging capacity – Up to 1 million logging sampling points per channel with 2 memory buffers per portMaximum safe input power – +16 dBmMeasurement units – dB and dBmOptical connector – FC typeMainframe compatibility – Designed for MPM-210/MPM-220 mainframes; up to 5 modules per mainframe (up to 20 ports total)ApplicationsInsertion loss (IL) and polarization-dependent loss (PDL) measurementsMulti-port optical device characterization (DWDM, AWG, WSS)Wavelength-dependent loss (WDL) testingAutomated swept test systems with Santec TSL tunable lasersProduction line quality inspection for optical switches, splitters, and couplersPhotonic integrated circuit (PIC) multi-waveguide optical parameter characterization
