Arbitrary waveform signal generator

Key Features & SpecificationsThe Tektronix AWG610 is a high-performance arbitrary waveform generator designed for testing high-speed devices and subsystems.Core Specifications:Maximum Sample Rate: 2.6 GS/sOutput Bandwidth: Up to over 800 MHzVertical Resolution: 8 bitsWaveform Length: 512 to 8,100,032 points in multiples of eightSequence Length: 1 to 8,000 stepsSequence Repeat Counter: 1 to 65,536 or infiniteRecord Length: 8 M wordsFunction Generator Mode Max Frequency: 260 MHzKey Applications:Disk Drive Read/Write Design and TestCommunications Design and Test – generates PRBS for physical layer testing (ITU-T, Fibre Channel, SDH/Sonet, Ethernet standards)Pulse generation with duty cycle from 0% to 100%Real-world signal simulations including noise, jitter, crosstalk, intersymbol effects, reflections, and ground bounce
