Synthetic Signal Generator

Key FeaturesWide Frequency Coverage: Operates from 10 MHz to 40 GHz, covering a broad range of microwave and millimeter-wave frequency bands with a single synthesizer.High Output Power: Delivers up to +29 dBm @ 1 GHz of CW output power (specified as +27 dBm @ 1 GHz), providing higher drive to simplify test setups.Excellent Signal Purity: Features low harmonic levels (better than -30 dBc) and excellent phase noise performance (-98 dBc/Hz @ 10 kHz offset @ 10 GHz).High Spurious Rejection: Provides spurious rejection of -70 dBc @ 10 GHz.Fine Resolution: Offers 1 Hz frequency resolution and 0.1 dB power resolution, with a dynamic range of >60 dB.Fast Switching Speed: Features a fast frequency switching speed of 500 μs for efficient testing.Compact and Lightweight: Designed as a compact and lightweight frequency generator, well-suited for integration into various test environments.Flexible Interfaces: Includes USB, GPIB, and Ethernet interfaces for easy integration and manual or software control.SCPI-Based: Supports SCPI-based operation for CW and stepped sweep modes.
