oscilloscope

The TDS3032 is a 300 MHz, 2-channel digital phosphor oscilloscope from the TDS3000 series. It provides advanced waveform capture, display, and measurement capabilities. The DPO technology delivers three dimensions of signal information (amplitude, time, and distribution of amplitude over time) in real-time.CategorySpecificationChannels2Bandwidth300 MHzSample Rate2.5 GS/s on each channelRecord Length10 kptsRise Time1.2 nsVertical Resolution9-bitDisplayFull VGA Color LCDAutomatic Measurements21FFTStandardTriggersAdvanced triggers, such as Glitch, Width, and LogicInterfaces & Additional Features:Storage: Built-in floppy disk drive; Front-panel USB host port (on 'C' models).Ports: Centronics port standard for quick hardcopies; Optional modules for RS-232, GPIB, LAN, or VGA communication ports.Probe Support: Supports active, differential, and current probes with automatic scaling and units.Application Modules: Optional modules for Telecommunications Mask Testing (TMT) and Extended Video applications.User Interface: Multi-language and QuickMenu mode for quick, easy operation.Note: This product is part of the TDS3000 series. The newer model is the TDS3032C.
